Technical specifications:
Channels 16 line inputs (8 mono and 4 stereo)
Groups 4 Group buses + ST bus
AUX Input 2 Aux Sends + 2 FX Sends
Compressor CH1-8, HPF (100 Hz, 12 dB / octave)
EQ Section Mono: ± 15dB (Max.), High 8kHz shelf / Mid 250Hz-5kHz peak (CH1-8,9-16) / Low 125Hz shelf
Stereo: ± 15dB (Max.): High 8kHz shelf / Mid 2.5kHz peak (CH9-12) / Low 125Hz shelf
Effects FX1: REV-X (8 Programs, Parameter control),
FX2: SPX (16 Programs, Parameter control)
Microphone inputs 10, (100Hz 12dB / octave)
Phantom Power 48V phantom power per channel
Line inputs: 8mono + 4stereo
Channel insert: 8
Return: 1 stereo
2TR IN: 1 stereo
Digital I/O USB audio USB in: iPod, iPhone exclusive
THD 0.02% (20Hz-20kHz @ + 14dBu)
Frequency response + 0.5 / -1.0dB 20Hz - 20kHz, nominal output level at 1kHz
EIN -128 dBu (20Hz-20 kHz, Rs = 150Ω, input gain = maximum)
Residual Output Noise -102 dBu (20Hz-20 kHz, Rs = 150Ω, input gain = maximum)
Crosstalk -74dB @ 1kHz
Power requirements 100-240V 50Hz / 60Hz
Consumption: 55W
Dimensions (WxHxD) 17.59 x 5.62 x 19.48 ″ (447 x 143 x 495mm)
Weight 19.84lb (9kg)
