BOSCH LHM0606 / 10 6 6W 100V Ceiling speaker specifications:
Maximum power: 9 W
Nominal power: 6/3 / 1.5 W
Sound pressure level at 6 W / 1 W (1 kHz, 1 m): 92 dB / 84 dB (SPL)
Effective frequency range (-10 dB) from 80 Hz to 18 kHz
1 kHz / 4 kHz (-6 dB) opening angle 175 ° / 55 °
Nominal voltage: 100 V
Nominal resistance: 1667 Ohm
Diameter 199 mm (7.8 inches)
Maximum depth 70.5 mm (2.8 inches)
Ceiling thickness from 9 to 25 mm (from 0.35 to 0.98 inches)
Cutout 165 mm + 5 mm (6.5 in + 0.2 in.)
Speaker diameter 152.4 mm (6 inches)
Weight 620 g (1.37 lbs)
Color White (RAL 9010)
BOSCH LHM0606 / 10 6 6W 100V CEILING SPEAKER
Maximum power 9 W
Nominal power 6/3 / 1.5 W
Sound pressure level at 6 W / 1 W (1 kHz, 1 m) 92 dB / 84 dB (SPL)
Effective frequency range (-10 dB) from 80 Hz to 18 kHz
Opening angle at 1 kHz / 4 kHz (-6 dB) 175 ° / 55 °
Nominal voltage 100 V
Nominal resistance 1667 Ohm
Diameter 199 mm (7.8 inches)
Maximum depth 70.5 mm (2.8 inches)
Ceiling thickness from 9 to 25 mm (from 0.35 to 0.98 inches)
Cutout 165 mm 5 mm (6.5 inches 0.2 inches)
Speaker diameter 152.4 mm (6 inches)
Weight 620 g (1.37 lbs)
Color White (RAL 9010)
Address: N. Nərimanov, Əhməd Rəcəbli 230.
AKUSTIKA music equipment sales store.
